ECG-125 1N-4007 Rectifier Diode 1000V DO-41
ECG-125 1N-4007 Rectifier Diode 1000V DO-41
Regular price
$1.23 USD
Regular price
Sale price
$1.23 USD
Shipping calculated at checkout.
10 in stock
Couldn't load pickup availability
ITEM SPECIFICS
Brand: ECG / Philips ECG Relays catalog attribution
MPN: ECG-125
Alternate marking on bag: 1N-4007
Visible body marking: ECG 125
Type: Axial rectifier diode
Label notation: R-Si
Maximum reverse voltage: 1000 PRV
Current rating: 1A per NTE125 datasheet; bag label states 2.5A
Package/case marking: DO-41
Configuration: Single diode
Condition: New
Quantity: 1
Country of origin: Not verified
DESCRIPTION
New ECG-125 axial rectifier diode from a labeled stock bag.
The photographed bag is marked exactly:
ECG-125
1N-4007
R-Si
1000 PRV
2.5 A
DO-41
The individual diode body is visibly marked “ECG 125.” Philips ECG Relays is the catalog manufacturer attribution for this part, although no separate Philips logo is visible on the photographed component.
NTE's current NTE125 datasheet rates this part at 1000V and 1A average forward current; the 2.5A figure appears on the bag label only. Please verify the part number, ratings, package, and circuit requirements before installation.
DISCLAIMER
Please review all photos and item specifics carefully before purchase. This item is new and untested. Please confirm compatibility and application requirements before installation. Returns are handled according to policies specific to this platform.
LEGAL DISCLAIMER
Philips and ECG are trademarks of their respective owners. American Industrial Parts Group is an independent seller and is not an authorized distributor or representative of Philips or ECG. This listing is for the specified component shown and described.
COMPATIBILITY & CROSS-REFERENCE
ECG-125 is the ECG number for NTE's NTE125 general-purpose silicon rectifier, rated 1000V peak repetitive reverse voltage and 1A average forward current with a 50A non-repetitive surge rating in a DO-41 axial package. The bag cross-references the 1N4007, the 1000V member of the 1N4001 to 1N4007 series, which carries the same 1A, 1000V, DO-41 ratings. Use it where a 1N4007 or NTE125 is specified; do not use it in positions that need more than 1A continuous.
Q&A
Q: What are the ratings of the ECG-125? A: 1000V, 1A average forward current, 50A surge, DO-41, per NTE's NTE125 datasheet.
Q: Why does the bag say 2.5A? A: The 2.5A figure appears on the bag label only; NTE's datasheet rates the part at 1A.
Q: Does it replace a 1N4007? A: Yes; the bag cross-references the 1N4007, which has the same 1000V, 1A, DO-41 ratings.
Q: How many are included? A: One.
ECG-125 diode, ECG 125 rectifier, NTE125, Philips ECG Relays diode, 1N-4007 marking, 1N4007 rectifier, 1 amp rectifier, 1000 PRV diode, 1000V rectifier, DO-41 axial diode, silicon rectifier, through-hole diode, obsolete semiconductor, replacement rectifier, electronic components, industrial parts, repair stock, untested diode, rectifier diode shorted replacement, power supply not rectifying
Thank you for shopping with American Industrial Parts Group!
