Lot of 10 Texas Instruments SN74S15N Triple 3-Input AND Gate DIP-14 NOS
Lot of 10 Texas Instruments SN74S15N Triple 3-Input AND Gate DIP-14 NOS
Regular price
$27.99 USD
Regular price
Sale price
$27.99 USD
Shipping calculated at checkout.
1 in stock
Couldn't load pickup availability
ITEM SPECIFICS
Brand: Texas Instruments
Model: SN74S15N
MPN: SN74S15N
Series: 74S
Type: Logic Gate Integrated Circuit
Logic Function: Triple 3-Input Positive-AND Gate
Number of Gates: 3
Inputs per Gate: 3
Output Type: Open Collector
Logic Family: Schottky TTL / S-TTL
Supply Voltage: 4.75V to 5.25V
Package/Case: 14-Pin Plastic DIP
Number of Pins: 14
Mounting Style: Through-Hole
Operating Temperature Range: 0°C to 70°C
Package Marking: 7702 / El Salvador
Quantity: 10
Condition: New Old Stock
DESCRIPTION
Lot of ten Texas Instruments SN74S15N Schottky TTL logic integrated circuits. Each SN74S15N contains three independent three-input positive-AND gates with open-collector outputs.
These vintage 74S-series logic devices are suitable for maintenance, repair, restoration, prototyping, and replacement applications requiring the original SN74S15N logic function and DIP-14 package.
Features:
Texas Instruments SN74S15N
Triple 3-Input Positive-AND Gate
Three Independent Logic Gates
Open-Collector Outputs
Schottky TTL / S-TTL Logic Family
4.75V to 5.25V Recommended Supply Range
14-Pin Plastic Dual-In-Line Package
Through-Hole Mounting
0°C to 70°C Operating Temperature Range
Matching 7702 Package Markings
El Salvador Marking
Lot of 10
These integrated circuits are new old stock from long-term storage. The pins show varying degrees of oxidation, tarnish, discoloration, and storage wear, as visible in the photos. No original packaging or documentation is included.
Please review all photos carefully for the exact markings, cosmetic condition, and included components.
COMPATIBILITY & CROSS-REFERENCE
The SN74S15N is a triple 3-input positive-AND gate with open-collector outputs in Schottky TTL, in a 14-pin plastic DIP. Verify pinout, pull-up requirements, and suitability for your circuit before installation.
Q: What does the SN74S15N do?
A: It contains three independent 3-input positive-AND gates with open-collector outputs.
Q: What is the supply voltage range?
A: 4.75 V to 5.25 V.
Q: How many are included?
A: Lot of 10 SN74S15N integrated circuits.
