Motorola MJ4030 PNP Darlington Power Transistor 60V 16A 150W TO-3 NOS
Motorola MJ4030 PNP Darlington Power Transistor 60V 16A 150W TO-3 NOS
Regular price
$14.00 USD
Regular price
Sale price
$14.00 USD
Shipping calculated at checkout.
Couldn't load pickup availability
ITEM SPECIFICS
Brand: Motorola
Model: MJ4030
MPN: MJ4030
Type: PNP Darlington Power Transistor
Transistor Polarity: PNP
Semiconductor Material: Silicon
Collector-Emitter Voltage: 60V
Collector-Base Voltage: 60V
Emitter-Base Voltage: 5V
Maximum Collector Current: 16A
Maximum Base Current: 0.5A
Maximum Power Dissipation: 150W
Minimum DC Current Gain: 1000 at 10A
Package/Case: TO-3
Number of Leads: 2
Mounting Style: Chassis Mount / Through-Hole
Complementary NPN Device: MJ4033
Condition: New Old Stock
DESCRIPTION
Motorola MJ4030 PNP silicon Darlington power transistor designed for use as an output device in complementary general-purpose amplifier applications.
Features:
Motorola MJ4030
PNP Darlington configuration
60V collector-emitter voltage
60V collector-base voltage
16A maximum collector current
150W maximum power dissipation
High DC current gain
TO-3 metal package
Two leads with collector connected to the case
Complementary NPN device: MJ4033
New old stock component. The unit may show cosmetic marks, surface discoloration, or oxidation from long-term storage and handling. No original manufacturer packaging is included. Please review all photos for the exact condition and markings of the item being offered.
DISCLAIMER
This item is new old stock. It may show cosmetic marks, surface discoloration, or oxidation from long-term storage and handling. Please review all photos for exact condition. Ships fast with tracking. 30-day returns accepted; buyer pays return shipping.
LEGAL DISCLAIMER
We are not an authorized distributor, reseller, or representative of Motorola. All product names, trademarks, brands, and logos are the property of their respective owners. Products are sourced from surplus inventory and are not covered by manufacturer warranties.
COMPATIBILITY & CROSS-REFERENCE
The MJ4030 is a PNP silicon Darlington power transistor in a TO-3 package and is part of the MJ4030 / MJ4031 / MJ4032 PNP family, rated 60V, 80V and 100V respectively; the complementary NPN devices are the MJ4033 / MJ4034 / MJ4035. Published ratings for the MJ4030 are 60V collector-emitter and collector-base, 5V emitter-base, 16A collector current, 0.5A base current and 150W dissipation at a case temperature of 25°C, with monolithic Darlington construction and a built-in base-emitter shunt resistor giving very high DC current gain. The type was second-sourced by several manufacturers, including Continental Device India (CDIL), Mospec and New Jersey Semiconductor. The collector is connected to the case, so the package must be insulated from a grounded heatsink where the circuit requires it.
