Siemens 3RV2011-1BA15 Sirius Motor Starter Protector 1.4-2A 3-Pole New No Box

ITEM SPECIFICS
Brand: Siemens
Model: 3RV2011-1BA15
MPN: 3RV2011-1BA15
Series: SIRIUS 3RV2
Type: Motor Protection Circuit Breaker / Manual Motor Starter Protector
Number of Poles: 3
Frame Size: S00
Adjustable Overload Range: 1.4–2 A
Instantaneous Short-Circuit Release: 26 A
Trip Class: Class 10
Auxiliary Contacts: 1 NO + 1 NC
Normally Open Terminals: 13–14
Normally Closed Terminals: 21–22
Terminal Type: Screw Terminals
Operation: Manual Rotary Handle
Country of Origin: Germany
Condition: New – Open Box
Packaging: No original box
Quantity: 1

DESCRIPTION
Siemens SIRIUS 3RV2011-1BA15 motor starter protector for motor overload and short-circuit protection. Features three main poles, an adjustable 1.4–2 A overload setting, Class 10 tripping, and front-mounted normally open and normally closed auxiliary contacts.
New, unused, out of box.
Includes the auxiliary contact assembly shown.
Rotary handle with ON, OFF, and tripped indications.
Screw-terminal connections for main and auxiliary circuits.
Original manufacturer packaging is not included.
Includes only the item shown in the photographs.

COMPATIBILITY & CROSS-REFERENCE
Direct replacement for the Siemens 3RV2011-1BA15 in S00 motor starter applications for motors drawing 1.4 to 2 A. The -15 suffix indicates the version supplied with a transverse 1 NO + 1 NC auxiliary contact; the 3RV2011-1BA10 is the same 1.4–2 A breaker without the auxiliary contact. Neighboring S00 setting ranges are the 3RV2011-1AA15 (1.1–1.6 A) and 3RV2011-1CA15 (1.8–2.5 A). It mounts on 35 mm DIN rail and combines with SIRIUS 3RT2 S00 contactors using Siemens link modules. Set the dial to the motor's full-load current.

Q&A
Q: What motor current does the 3RV2011-1BA15 cover? A: Its overload release adjusts from 1.4 to 2 A.
Q: What trip class is it? A: Class 10.
Q: What does the -15 suffix mean? A: It is supplied with a 1 NO + 1 NC auxiliary contact (terminals 13-14 and 21-22).
Q: What frame size is it? A: SIRIUS S00.

DISCLAIMER
New, unused item supplied without its original box. Please review all photographs for physical condition and included components. Buyer is responsible for verifying the exact part number, motor current, circuit ratings, and application requirements before installation.
